- General Information
- Manufacturer
- Tenda Technology Inc
- Manufacturer Website Address
- http://www.tendaus.com
- Brand Name
- Tenda
- Product Type
- Ethernet Switch
F1109P-8-102W is a IP-COM switch that offers 9 10/100M RJ45 ports. Ports 1-8 comply with the IEEE802.3af standard (maximum PoE power output : 15.4w) and 802.3at standard (maximum PoE power output: 30W). The switch offers a maximum PoE power output of 92W and can supply power to exchange data with APs, IP cameras, and IP phones through CAT5e cables. It also provides simple management modes such as Standard, VLAN. Thus, F1109P-8-102W is a perfect choice for SMBs, hotels, and office to have small-scale HD surveillance and wireless networking
- Technical Information
- Features
- Fanless
- Interfaces/Ports
- Total Number of Network Ports
- 9
- Uplink Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 8 x Fast Ethernet PoE
- 1 x Fast Ethernet Network
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 100Base-T
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3af
- IEEE 802.3at
- Management & Protocols
- Manageable
- No
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 92 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- Power Supply
- PoE
- AC
- Power Consumption
- 102 W
- Physical Characteristics
- Form Factor
- Desktop
- Height
- 1"
- Width
- 7"
- Depth
- 4.1"
- Miscellaneous
- Application/Usage
- Network
- Server
- IP Camera
- IP Phone
- Surveillance
- Hotel
- Office
