- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Type
- Modem/Wireless Router
Industrial cellular router ICR-2432 is designed for wireless communication in the mobile networks that make use of traditional cellular technologies. The primary purpose of this router is its use in the Category 4 (Cat.4) services on the cellular LTE network. Cat.4 rated ICR-2432 router is capable of achieving better typical speeds in 4G coverage areas where the network is enabled with 20 MHz of contiguous spectrum. The peak downlink data rate for a Category 4 is approximately 150 Mbps. Also in the uplink, LTE Category 4 provides a peak data rate of 50 Mbps. Optional built-in WiFi 802.11a,b,g,n with AP, Client and Multirole modes are available.
The router is equipped with two independently configurable Ethernet ports (LAN or WAN), 1× serial port RS232, 1× RS485, and with digital I/O connectivity (1× DI, 1× DO). The router supports VPN tunnel creation using various protocols to ensure safe communications. The router provides diagnostic functions which include automatic monitoring of the wireless and wired connections, automatic restart in case of connection losses, and a hardware watchdog that monitors the router status.
Router is based on ICR-OS operation system. Open Linux platform enable wide possibilities of programming customer SW applications in Python, C/C++. Router supports uploading of RouterApps (User modules) that would extend standard firmware functionalities. Existing app library ready for free download by customer contains already developed software apps to enhance specific router functionality including industrial protocol conversions, support of IoT platforms such as MS Azure, Cumulocity, and a lot more. The router is easy to manage using WebAccess/DMP a full-featured, cloud-based platform for device management, provisioning, and monitoring. It is ideal for mass deployment and VPN management, enabling secure remote access.
- Technical Information
- Processor Model
- ARM926EJ-S
- Processor Speed
- 600 MHz
- Standard Memory
- 128 MB
- Wireless Specifications
- Broadband Transmission Technology
- Cellular
- Ethernet
- Cellular Generation
- 4G
- Cellular Data Connectivity Technology
- UMTS
- EDGE
- GPRS
- LTE Cat 4
- HSPA+
- Total Wireless Transmission Speed
- 18.75 MB/s
- Encryption Standard
- DES
- 3DES
- AES
- RSA
- MD5
- SHA
- Firewall Type
- NAT
- PAT
- Interfaces/Ports
- Total Number of Network Ports
- 2
- Number of Network (RJ-45) Ports
- 1
- Number of Broadband (RJ-45) Ports
- 1
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- VPN Supported
- Yes
- Multi-SIM Supported
- Yes
- Number of SIM Card Supported
- 2
- SIM Size Supported
- Micro
- Storage
- Flash Memory Capacity
- 64 MB
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- Wall Mountable
- DIN Rail Mountable
- Height
- 1"
- Width
- 4.1"
- Depth
- 3.7"
- Weight (Approximate)
- 12.17 oz
- Miscellaneous
- Package Contents
- ICR-2432 Modem/Wireless Router
- 6-pin PWR / IO Connector
- 7-pin Serial Connector
- Wall Mount Kit
- Certifications & Standards
- EN 301 511
- EN 301 908-1
- EN 301 908-2
- EN 301 908-13
- EN 301 893
- EN 300 328
- ETSI EN 301 489-1
- ETSI EN 301 489-17
- ETSI EN 301 489-52
- IEC 61000-6-2
- IEC 61000-6-3
- EN 61000-4-2
- EN IEC 61000-4-3
- EN 61000-4-4
- EN 61000-4-5,
- EN 61000-4-6
- EN 55032
- EN 62 368-1
- IEEE 802.3
- EN 18031-1
- CE
- UKCA
- Anatel
- EN 60529
- EN 60068-2-1
- EN 60068-2-2
- EN 60068-2-14
- EN 60068-2-30
- FCC
- NCC
- RCM
- ICASA
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Restriction of Hazardous Substances (RoHS) 3
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Country of Origin
- United States
